PVC strip courtains datasheet |
||||
| Propiedad Property | Norma Standard | Refrigeración Refrigeration | Congelación Freezing | Unidad Units |
| Espesor | 2 | 3 | mm | |
| Thickness | ||||
| Densidad | (ASTM C 177) | 1,22 | 1,18 | g/cm3 |
| Density | ||||
| Temperatura de rotura al frío | (ISO 8570) | -35 | -40 | ºC |
| Cold bend brittle temp | ||||
| Temperatura máxima de servicio | (EN 1876) | 50 | 30 | ºC |
| Max. usage temp | ||||
| Temperatura mínima de servicio | (EN 1876) | -15 | -25 | ºC |
| Min. usage temp | ||||
| Dureza | (EN ISO 868) | 80 | 65 | Sh A |
| Shore A hardness | ||||
| Elongación a la rotura | ASTM D 638 EN ISO 527 | 340 | 390 | % |
| Elongation at break | ||||
| Resistencia a la rotura | 16 | 12 | N/mm2 | |
| Tensible strenght at break | ||||
| Absorción de agua | EN ISO 62 | -0,2 | -0,2 | % |
| Water absorption | ||||
| Protección al sonido | DIN 52210 | 35 | 35 | dB |
| Sound reduction | ||||
| Resistencia al fuego | DIN 4102 AS/NZS 3837 NF P 92-507 | Grp4/B2 | Grp4/B2 | Grado Grade |
| Reaction to fire | ||||
| Resistencia UV | ISO 4892 | Si Yes | Si Yes | – |
| UV resistance | ||||
| Transmisión de la luz | EN 1598 | 85 | 85 | % |
| IR Filter | ||||
| Capacidad termica | ISO 11357 | 1,6 | 1,6 | kJ/kg·K |
| Specific heat capacity | ||||
| Conductividad térmica | ASTM 177 | 0,16 | 0,16 | W/m·K |
| Thermal conductivity | ||||
PVC STRIP COURTAINS
The curtains minimizes the airfl ow in the openings of the refrigerator doors, reducing the thermal load. Very useful for refrigeration and rooms with hygienic special needs.
– A fitted curtain to hang inside the coldroom that doesn’t obstruct the
doorway.
– All fittings and screws are made of stainless steel and suitable for the food
industry and industrial refrigeration.
– The width of the PVC strips is 200mm, with an overlap of between 50mm
and 60mm
– Individually interchangeable strips.
Instalation:
– Easy and quick installation.
– Drill screws are provided made of stainless steel.
– Alternative placing for strips in order to improve the efficiency.
We are the manufacturers of the strip curtains, and can supply curtains for any door sizes. Please consult our technical sales department.
